HBS-62.5Z high-precision measurement automatic display direct reading small load soft metal Brinell hardness tester

https://shmuker.oss-cn-hangzhou.aliyuncs.com/data/oss/67d923ec46c0fb5645dad7ee/67d936a5a09b7b35f9a6db40/20250324114119/Brinell-Hardness-TesterHBS-62.5Z-1.jpg
Specific Information
Please contact us

Refunds

If there is any problem with the goods, we will solve it for you in time。
Product Specifications Reference
Test force
1kgf、5kgf、10kgf、15.625kgf、30kgf、62.5kgf
Max. allowable height of test piece
175mm
Distance from center of indenter to machine wall
125mm
Power supply
AC220V,50Hz
Measurement system magnification
50X 100X

Payment method

COMM
COMM
Product Details
Product Introduction
Introducing the HBS-62.5Z Small Load Automatic Turret Digital Brinell Hardness Tester from Laizhou Jincheng Industrial Equipment Co., Ltd. Our brand Jincheng is committed to providing high-quality testing equipment. This tester is particularly suitable for softer metals such as pure aluminum, copper, lead, tin and zinc. It has high measurement accuracy, good reproducibility and representativeness. It adopts automatic digital display to eliminate human reading errors. The solid structure ensures durability and high testing efficiency. The testing process is automated, and the LCD screen with menu operation provides complete functions such as data processing and hardness conversion. It is a reliable choice for hardness testing needs in various industries.
Advantages and features
1. The large-screen LCD displays the operation process and test result data. Just measure the indentation and press the eyepiece button to automatically calculate and display the hardness value.
2. The experimental results data can be output via printer.
3. Strong structure, good rigidity, accuracy, reliability and durability to ensure long-term use.
4. Automatic turret mode improves test efficiency and accuracy.
Application Scenario
This product is widely used in machinery manufacturing, metallurgy, chemical industry and other industries. It is suitable for markets such as Russia, Southeast Asia, and Europe. Customers include large metallurgical enterprises, universities, and scientific research institutions. It can meet the hardness testing needs of various scenarios and provide accurate data for quality control and scientific research.
Product Parameters
Turret mode: Automatic turret
Dimensions: 600*260*650mm
Weight : 65Kg
Type Specification Unit Quantity
Brinell hardness tester set 1
Big flat workbench pc 1
Small flat workbench pc 1
V-shaped workbench pc 1
Hard alloy indenter Φ1、φ2.5 pc 1
Digital micrometer eyepiece 10X pc 1
Standard Brinell hardness block 1 100±25HBW 10/1000 pc 1
standard Brinell hardness block 2 200±50HBW 10/3000 pc 1
Insurance wire pc 2
Level instrument pc 1
Level adjustment screw pc 4
Allen wrench pc 1
Accessories box pc 1
Dust cover pc 1
Manual sheet 1
Power cable pc 1
Certificate sheet 1
